Do you encounter difficulties in product processing and positioning during manufacturing? Is it a problem of low assembly efficiency? precionn can solve these problems for you. precionn is a professional fixture designer and manufacturer with a professional design team, especially in PCB, ICT assembly test fixtures and automobile assembly fixtures with rich experience.

Different Types of Fixture Design and Manufacturing

Basic Principles of Fixture Design and Manufacturing

1. Reasonable positioning. The design of the fixture must ensure accurate positioning to the processing position. By designing appropriate positioning mechanisms, such as pins and positioning blocks, the workpiece can be quickly and accurately positioned in the fixture and can be clamped quickly and stably.


2. Rigid support. The fixture must have sufficient stiffness and stability to ensure that the workpiece does not shift or deform during processing or assembly. When designing, the weight and shape of the workpiece should be considered, the support points should be reasonably arranged, and the rigidity of the fixture should be increased.


3. Stable clamping. The fixture should hold the workpiece securely to prevent slipping or rotation during machining or installation. Commonly used clamping methods include mechanical clamping, hydraulic clamping, and pneumatic clamping. Choose the appropriate clamping method according to the requirements of the workpiece.


4. Safe and reliable. The clamp design must consider the safety of the operator. For hydraulic clamping and pneumatic clamping, a sensing device needs to be installed when necessary to prevent accidental injuries during use.


Applications of Fixture Design and Manufacturing

1. Mechanical processing industry. The main function of the fixture is to ensure the relative position accuracy of parts, improve production efficiency, reduce processing costs, and improve the working conditions of operators.


2. Consumer electronics assembly industry. Global consumer electronics products have a fast update cycle, and assembly is a labor-intensive industry. Reasonable assembly fixtures can improve product assembly efficiency and reduce manpower.


3. Automotive industry assembly, welding and other processes. The automotive industry is a highly automated industry. There are high requirements for product placement and positioning during assembly and welding. Precision assembly fixtures can improve the assembly accuracy of automobiles and improve assembly efficiency.


4. PCB and ICT testing in the chip industry. Functional testing of finished chips requires professional testing fixtures.
